Expand : LoRa Pager

Expand : LoRa Pager

$70.00 $42.00 SALE

Custom built for you. Ships in 7–14 days. We’ll email you about any delays.

** Upgrade notice**
If you previously purchased a device that contains "Expand : LoRa / GPS Junior", you can get 40% off to upgrade to Expand : LoRa Pager or Expand : LoRa Pager and a free matching frame.
Please leave a note at checkout with your original order number to claim this offer.


LoRa communication with vibration, audible alerts, and microSD storage.

Expand: LoRa Pager adds vibration, a buzzer, and a microSD card slot to your Attaky LoRa setup. These features give compatible firmware the hardware for tactile notifications, audible alerts, and applications that use removable storage.

It also delivers higher measured RF output than LoRa / GPS Junior in our testing. Choose Pager when you want the additional alert and storage hardware for your next communication project.

Highlights

·         LoRa radio for communication with compatible devices and firmware.

·         Vibration hardware for tactile alerts when supported by the installed firmware.

·         Buzzer for audible notifications when supported by the installed firmware.

·         microSD card slot for firmware that uses removable storage.

·         Measured RF output in our testing: 20.6 dBm, approximately 0.1148 W.

·         Module dimensions: 66 × 46 × 18 mm, excluding the antenna.

What you receive

1 × Expand: LoRa Pager 1.0 module.

1 x mini LoRa Antenna

Before you use it

Requires an Attaky Core, a suitable LoRa antenna, and firmware that supports this module. Vibration, buzzer behaviour, and microSD functions depend on the installed firmware. Attach the antenna before transmitting.

The RF output above is a measurement from our tests, not an official manufacturer specification or a guaranteed output for every unit. It does not establish a fixed communication range. Actual results may vary with configuration and test conditions.

The transmit output above is a result from our own testing. It is not a certified or guaranteed output specification; results can vary with configuration and test conditions.


Early Module Access

We made Attaky modules available earlier than planned because some community members have already requested them.

Video tutorials are coming soon, including guides for frame installation, module swapping, and connecting different Attaky modules together.

In the meantime, our written documentation and module specifications are already available. If you are comfortable reading specs, pinouts, compatibility notes, and word-based setup guides, you can review the documentation first and order modules now.

Please note that our configurator currently focuses on complete build combinations, so module-level Lab Access visual previews are not available yet. You can still use the configurator to explore colors, layouts, and build directions, then message us with your idea. We can help customize a Lab Access module setup for your project.

Please check the specs carefully before ordering to make sure the module matches your build, frame, firmware, and project needs.


Please find word-based documentation at:

https://docs.attaky.com/docs/modules/expand/lora-gps
